R1 series kinetic switch adopts MEA (Micro Energy Acquisition) technology, efficiently converting kinetic energy from the user's press into electrical energy.
Versatile Pairing for Two-way and Multiple Control
It allows multiple units to pair with each other, achieving two-way control and multiple units controlling one or one controlling multiple units.
The switch can be mounted on the wall with a sticker, fixed with a bottom plate, or mounted with a bracket.
Completely wireless. Powered by kinetic energy generated from simply pressing the switch.
Mount the switch with adhesive tape.
Ensures you a press feeling always pleasant. A discreet “click” allows you to have a good feedback.
Can be used as remote control.
Examples Of Use Cases
R1 118-type wireless kinetic switch
| Working Type | Push button |
| Power Supply | Self-powered |
| Modulation System | FSK |
| Radio frequency | RF 433MHz |
| Keys Quantity | 1key/2key/3key |
| Operate Range | up to 80m outdoors,up to 25m indoors(May vary depending on conditions) |
| Life Time | ≥100,000 times |
| Color | white/silver/golden |
| Dimension | L75mm*W120*H15mm |
| Working Temperature | -20 ~ +55°C |
| Casing Material | PC |
Support & Questions
Please contact us if you need the datasheet.
