Wireless Kinetic Switches – No Batteries Needed
Pair with up to 10 wireless kinetic switches (battery-free, peel-and-stick) for multi-location control without wiring.
No Gateway Required
Direct pairing between smart switch and wireless switches eliminates the need for extra controllers or hubs, reducing cost and complexity.
US Standard Design
Built to US electrical standards, this switch fits standard wall boxes for easy retrofitting—upgrade to smart lighting in minutes.
Our ERC2303 wireless dimmer receiver can be paired with Ebelong wireless kinetic switch, which is wireless and battery-free.
One very small size product, can be hidden in the corner of furniture.
A wireless dimmer supporting PWM dimming. You can use an ERC2303 controller adjust the color temperature of light strip.
APP & voice control supported, a wonderful part of your smart home automation.
ERC2303 wireless dimmer receiver is a small low voltage DC PWM dimmer receiver, especially suitable for furniture lighting strip control.
Using an ERC2303 wireless dimmer receiver, upgrade your traditional wired devices to intelligent system.
Examples Of Use Cases
C11 series american standard neutral wire required wall switch
| Working Voltage | AC110V 50/60Hz |
| Power supply | ATwo wire: neutral & live wire |
| Dimming range | 0-100% |
| Power rating | LED 250W Resistive load: 500W |
| Radio frequency | RF version: RF 902MHz WiFi version: WiFi IEEE 802.11 b/g/n 2.4G & RF 902MHz |
| Operate range | up to 80m outdoors up to 25m indoors (May vary depending on conditions) |
| Standby power | <1.8W |
| Storage capacity | Storage of up to 10 wireless kinetic switch messages |
| Controller size | L44mm*W41mm*H107mm |
| Wireless switch size | L33mm*W16mm*H65mm |
| Wireless switch size | Connector |
| RF reception sensitivity | -110dBm |
| Operating temperature | -15℃ ~ +45℃ |
| Certifications and standards | USA UL 1472:2015 Ed.2+R:10Nov2017 CSA C22.2#184.1:2015 Ed.2+U1 UL 60730-1:2016 Ed.5 CSA E60730-1:2015 Ed.5+A1 |
Support & Questions
Please contact us if you need the datasheet.
